Description
Features:
Splicing time: 7-9 sec (SM FAST mode).
Heat time: 13-15 sec (for 60 mm sleeves).
Core alignment technology.
Advanced image processing technology.
Fiber discrimination function.
The faster automated features.
Time for opening wind protector is 80% lower comparing to the Fujikura 80S.
Time for placing fiber into heater is 50% lower comparing to the Fujikura 80S.
Easy fiber protection sleeve positioning.
The lid of the carrying case may be used as a work table.
Plenty of space in the carrying case. There are two drawers for storage, and the work tray can be divided into two separate places.
The sheath clamp is compatible with loose tube fiber.
Wireless data connectivity allows automatic cleaver blade rotation when the splicer judges the blade is worn.
The tool can connect two cleavers simultaneously.
Blade life management: the device displays the remaining blade life, informs about blade height and position change, and when new blade is required.
Operation manual is installed into the splicer.
Battery life increased up to 500 recharge cycles.
Increased electrode lifetime – up to 5000 splicing cycles with one set.
5-inch color TFT touch screen display.
Includes :
Splicer, Battery pack, AC adapter, AC power cord, USB cable, Fusion splicer srap, Electrodes(spare), Fiber holder set plate, Carrying case, Work tray, Tripod screw, Carrying case strap, Alcohol dispenser, Quick reference guide, Stripper, CT08 Cleaver
